- Auto-loop broadcast when power on
- Support AV and VGA video output simultaneously
- Support digit time display after power on
- Support USB to carry on the program upgrade directly
- Support video adjustment,reset and memory function
1.Auto-loop broadcast when power on
2.Support break-point memory function
3.Support spot announcement function
4.Support time swtich function
5.Support calendar function
6.Support big BMP Icon display
7.support long rolling caption display function
8.Auto record the log file of the broadcasting programs
9.Support USB to carry on the program upgrade directly
10.Support video adjustment,reset and memory function
11.support AV and VGA video output simultaneously
12.Support ID3 function when playing MP3
13 Support digit time display after power on
14.Support mute function when station reporting
15.Support high data rate VOB(DVD)document. Audio and video signals are still smooth and clear at 10M bps
16.Support documentation copy and deletion directly on this player .No need to carry on the complex operation on the computer.This function only supports USB to carry on the document copy to the CF card.Delete function is not affected by this restriction
| Detail | Specifications | |
| Screen Size | 21.5 inch | |
| Aspect Ratio | 16:9 | |
| Resolution | 1920 (H)×3 (RGB)×1080 (V) | |
| Contrast Ratio | 1000:1 | |
| Brightness | 400cd/m2 | |
| Response Period | 5 ms | |
| View Angle | U:80/D:80 L/R: 85 | |
| Light Source | LED | |
| OSD Language | Chinese and English (other languages optional) | |
| Analog Adjustments | Brightness, Contrast, Chrome(0~100) | |
| Color System | PAL/NTSC | |
| Video Input | 1VP-P75 Ω, VGA signal input (optional) | |
| Image Display | 16:9 | |
| Interface | HDMI , CVBS (RCA) VGA | |
| Power Supply | DC 10.5~32V | |
| Product Dimension | L: 600mm×W: 395mm×D: 130mm | |
| Net Weight | 5.6 KG | |
| Operating Temperature | -20~50°C | |
| Storage Temperature | -20~80°C | |
| Power Consumption | <30 W | |
